Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

EngineType2-stroke, 2-cylinder, water cooled gasoline engineBore & Stroke76mm x 68mm (2.99in. X 2.68in.)Piston displacement617cc ( 37.64 cu.in.)Authorized output40.8PS/ 30 kWFuel tank18 liters (4.76 US gals)Fuel consumption12 liters/h (3.17US gals/h.

Engine	Type	2-stroke, 2-cylinder, water cooled gasoline engine
	Bore & Stroke	76mm x 68mm (2.99in. X 2.68in.)
	Piston displacement	617cc ( 37.64 cu.in.)
	Authorized output	40.8PS/ 30 kW
	Fuel tank	18 liters (4.76 US gals)
	Fuel consumption	12 liters/h (3.17US gals/h.)
	Ignition	Flywheel magneto (C.D.I. system)
	Starting system	Starter motor and automatic recoil system
	Lubrication	Separate fuel/oil supply system (Auto mixing)
	Choke system	Auto choke system
	Spark plug	NGK BP7HS-10
	Light bulb	12V-35W
	Battery	12V-16Ah/5h
Pump	Type	Single suction, single stage, high pressure turbine pump
	Discharge port coupling	JIS fire thread (B-9912), 2-1/2" male
	Suction port coupling	JIS fire thread (B-9912), 3" male
	Priming	Rotary-vane vacuum pump (Oilless type)
Pump performance (Suction height: 3m)	Over 1,700 liters (Over 449 US gals)/min. at 0.4 MPa
	Over 1,550 liters (Over 409 US gals)/min. at 0.6 MPa
	Over 1,300 liters (Over 343 US gals)/min. at 0.8 MPa
	Over 950 liters (Over 251 US gals/min. at 1.0 MPa
Dimensions	Overall length	Approx. 700mm (27.6 inch)
	Overall width	Approx. 620mm (24.4 inch)
	Overall height	Approx. 730mm (28.7 inch)
Mass	85kg (187 lbs)
Max. suction height	Approx. 9m (29.5 feet)
