Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

SPECIFICATIONS INSULATION RESISTANCE Test Voltage (DC V) 250V / 500V / 1000V Output Ranges on Open Circuit Rated test voltage +/-10% Measuring Ranges 250V : 0-100M Ohm / 500V : 0-200M Ohm / 1000V : 0-400M Ohm Mid-Scale Vale 250V : 1M Ohm / 500V :

SPECIFICATIONS
INSULATION RESISTANCE
Test Voltage (DC V)	250V / 500V / 1000V
Output Ranges on Open Circuit	Rated test voltage +/-10%
Measuring Ranges	250V : 0-100M Ohm / 500V : 0-200M Ohm / 1000V : 0-400M Ohm
Mid-Scale Vale	250V : 1M Ohm / 500V : 2M Ohm / 1000V : 4M Ohm
Scale Multipliere	250V : x 1/2 / 500V : x 1 / 1000V : x 2
Accuracy	+/- 3% of indicated value
Output Short-Circuit Current	1.3 mA
CONTINUITY
Measuring Ranges	3 Ohm / 500 Ohm
Output Short-Circuit Current	250 mA
Accuracy	+/- 1.5% of scale length
AC VOLTAGE
AC Voltage Range	0 ~ 600V AC
Accuracy	+/- 3% of scale length
GENERAL
Voltage Warning	Warning light circuit live lit from 90Vdc/70Vac buzzer beep from 24Vac/dc
Battery Check	Battery check indicate good batteries from 8Vdc to 13Vdc during a load test of 240mA
Battery OK	Battery OK Led from 8Vdc and is operative while testing
Power Source	1.5V(SUM-3) x 8 Type AA
Dimension	175(L) x 85(W) x 75(D)mm
Weight	Approx. 650g (battery included)
Accessories	Test leads, fuse (0.25A 250V), instruction manual, batteries
