Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Voltage DCMaximum Voltage1000 VAccuracy±(0.2%+2)Maximum Resolution0.001VVoltage ACMaximum Voltage1000 VAccuracy±(2%+3)Maximum Resolution0.1 mVCurrent DCMaximum Amps400mAAmps Accuracy±(1.0%+2)Maximum Resolution0.01 mACurrent ACMaximum Amps400mAAmps

Voltage DC
Maximum Voltage	1000 V
Accuracy	±(0.2%+2)
Maximum Resolution	0.001V
Voltage AC
Maximum Voltage	1000 V
Accuracy	±(2%+3)
Maximum Resolution	0.1 mV
Current DC
Maximum Amps	400mA
Amps Accuracy	±(1.0%+2)
Maximum Resolution	0.01 mA
Current AC
Maximum Amps	400mA
Amps Accuracy	±(2.0%+2) 1kHz bandwidth
Maximum Resolution	0.01 mA
Resistance
Maximum Resistance	50 MΩ
Accuracy	±(1.2%+2)
Maximum Resolution	0.1Ω
Insulation Test
Minimum Test Current @ 1kΩ/V	1mA
Test Voltages	500, 1000 V
Maximum Resistance per Test Voltage	100V: 600 MΩ
Maximum Resolution per Test Voltage	50V: 0.01 MΩ 100V: 0.01 MΩ 250V: 0.1 MΩ 500V: 0.1 MΩ 100V: 0.1 MΩ
Accuracy per Test Voltage	50V: ±(3 % + 5) 100V: ±(3 % + 5) 250V: ±(1.5 % + 5) 500V: ±(2.0 % + 5) 100V: ±(2.0 % + 5)
Environmental Specifications
Operating temperature	–20 °C to +55 °C
Storage temperature	-40°C to +60°C
Humidity (Without Condensation)	0% - 95% (10 °C – 30 °C) 0% - 75% (30 °C – 40 °C) 0% - 40% (40 °C – 55 °C)
Operating Altitude	2000 m
Safety Specifications
Overvoltage category	Complies with ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA-C22.2 NO. 61010-1-04, and IEC/EN 61010-1 2nd Edition for measurement CAT III 1000 V and CAT IV 600 V
Agency Approvals	2000 m CAT III 1000 V, CAT IV 600 V; 3000 m CAT II 1000 V, CAT III 600 V
Mechanical & General Specifications
Size	203 x 100 x 50 mm (with holster)
Weight	624 g
Battery life Alkaline	Meter use 1000 hours
Insulation test use	Meter can perform at least 1000 insulation tests with fresh alkaline batteries at room temperature. These are standard tests of 1000 V into 1 MΩ with a duty cycle of 5 seconds on and 25 seconds off.
IP Rating	IP40
