Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Video System NTSC / PAL (auto detection) Video Compression Format H.264 Video Input 16 channels (Composite video signal 1 Vp-p 75Ω BNC) Video Loop Output 16 channels (Composite video signal 1 Vp-p 75Ω BNC) Video Output (BNC) Main Monitor : For stable

Video System	NTSC / PAL (auto detection)
Video Compression Format	H.264
Video Input	16 channels (Composite video signal 1 Vp-p 75Ω BNC)
Video Loop Output	16 channels (Composite video signal 1 Vp-p 75Ω BNC)
Video Output (BNC)	Main Monitor : For stable display
	Call Monitor : For sequence display
Video Output (VGA)	Built-in (Output resolution up to 1600 x 1200)
Audio Input / Output	4 audio inputs, 2 audio output (Mono)
Maximum Recording Rate	Frame : 704×480 pixels with 120 IPS / 704×576 pixels with 100 IPS
	Field : 704x240 pixels with 240 IPS / 704×288 pixels with 200 IPS
	CIF : 352×240 pixels with 480 IPS / 352×288 pixels with 400 IPS
DCCS Support	YES (CH1 ~ 4)
IVS Support	YES (4 channels)
Image Quality Setting	SUPER BEST / BEST / HIGH / NORMAL
Hard Disk Storage	Accommodates 2 SATA HDDs (1 HDD capacity up to 2TB)
Quick Search	Time / Motion / Alarm search mode
SATA Interface	Built-in
Recording Mode	Manual / Timer / Motion / Alarm / Remote
Multiplex Operation	Live display / record / playback / backup / network operations
USB Mouse Control	YES
Motion Detection Area	16 × 12 grids per channel
Motion Detection Sensitivity	3 adjustable parameters for accurate detection
Pre-alarm Recording	YES
Backup Device	USB 2.0 flash drive / Network
Web Transmitting Compression Format	H.264
Network Live Audio	YES
Ethernet	10/100 Base-T. Supports remote control and live view via Ethernet
Network Protocol	TCP/IP, PPPOE, DHCP and DDNS
Remote Independent Operation	YES
Event Notification	By FTP / E-Mail
R.E.T.R. (Remote Event Trigger Recording)	YES
IR Remote Control	YES (IR receiver built-in)
Mobile Surveillance	YES (Including iPhone, BlackBerry, Windows Mobile, & Symbian)
Remote Surveillance(Operating System: Windows 7 / Vista / XP)	CMS : Our self-developed and free software,"Video Viewer"
	Web Browser : Internet Explorer, Mozilla Firefox, Google Chrome, Apple Safari & Opera
	Media Player : QuickTime
	Max. on-line user : 10
Picture Zoom	2X digital zoom
PTZ Control	YES
Alarm I/O	16 inputs, 1 output
Key Lock (Password Protection)	YES
User Level	Administrator & Operator
Video Loss Detection	YES
Camera Title	Supports up to 12 letters
Image and Volume Editing	Hue / Color / Contrast / Bright / Volume
Date Display Format	YY/MM/DD, DD/MM/YY & MM/DD/YY
Daylight Saving	YES
Power Source (±10%)	DC 19V
Power Consumption (±10%)	< 64 W
Operating Temperature	10℃ ~ 40℃ (50℉~104℉)
Dimensions (mm)**	432(W) × 90(H) × 326(D)
System Recovery	System auto recovery after power failure
Optional Peripherals	Keyboard Controller
