Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Specification FI8608W Image Sensor Image Sensor 1/4"Color CMOS Sensor Display Resolution 640*480 Pixels(300k Pixels) Lens f: 3.6mm, F:2.4 (IR Lens) Mini. Illumination 0.5Lux Audio Input/Output Linear Input/Output, which can realize two-way voice the

Specification		FI8608W
Image Sensor	Image Sensor	1/4"Color CMOS Sensor
	Display Resolution	640*480 Pixels(300k Pixels)
	Lens	f: 3.6mm, F:2.4 (IR Lens)
	Mini. Illumination	0.5Lux
Audio	Input/Output	Linear Input/Output, which can realize two-way voice the intercom
	Audio Compression	G.711/G.726, Audio sampling Bit rate 128kbps ~ 2.048Mbps
Video	Image Compression	H.264
	Light Frequency	50Hz, 60Hz
	Image Resolution	VGA（640480），QVGA（320240），QQVGA（160*120）
	View	H.264 dual streaming
	Image adjust	The brightness, contrast, saturation, chromaticityt, is adjustable
	White balance	Automatic, Indoor, outdoor , is adjustable
	Infrared mode	Automatic , manual (on/off)
	Night visibility	Φ5mm 11 IR LEDs, Night visibility up to 8 metres
Network	Ethernet	One 10/100Mbps RJ-45
	Supported Protocol	TCP/IP、UDP/IP、HTTP、SMTP、FTP、DHCP、DDNS、UPNP
	Wireless Standard	WIFI(IEEE802.11b/g/n)
	Support IP address	static IP address, dynamic IP address
Alarm	Alarm detection	The motion detecting, detection threshold Settings
	Alarm inform	Support Email、FTP etc alarm inform way
Hardware Interface	SD CARD	SD CARD (Support to 32G)
	POWER Interface	DC 5V/2.0A (EU,US,AU adapter or other types optional), Power Consumption ﹤8 Watts
	Audio Input/ Output Interface	One audio input jack,One audio outputt jack.
	Reset Buttons	One Reset
	Ethernet	One 10/100Mbps RJ-45
	Wireless Interface	WIFI antenna
Other	Pan/Tilt Angle	Horizontal:270° & Vertical: 120°
	LED Explain	One SD CARD Instructions，One power Instructions
Physical	Dimension	117(L) x114(W) x129mm(H)
	Gross Weight	814g (Color Box Size:245x145x165mm)
	Net Weight	348g (accessories included)
Environment	Operate Temper	0° ~ 55°C (14°F ~ 122°F)
	Operate Humidity	10% ~ 80% non-condensing
	Storage Temper	~ 60° (14°F ~ 140°F)
	Storage Humidity	0% ~ 90% non-condensing
PC Requirements	CPU	2.0GHZ or above (suggested 3.0GHz)
	Memory Size	256MB or above (suggested 1.0GHz)
	Display Card	64M or above
	Supported OS	Microsoft Windows 2000/XP,Vista,Windows7,Mac OS,Linux
	Browser	IE6 and above version or compatible browser, Firefox or other standard browsers
Certificate	CE,FCC	CE,FCC
