Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Pick-Up Element 1/3" Sony Effio CCD Image Sensor Image Signal Process Digital Signal Processor System of Signal NTSC / PAL Number of Pixels NTSC: 1020(H)x508(V) / PAL: 1020(H)x596(V) Picture Elements NTSC: 520K Approx. / PAL: 610K Approx. Horizontal

Pick-Up Element	1/3" Sony Effio CCD Image Sensor
Image Signal Process	Digital Signal Processor
System of Signal	NTSC / PAL
Number of Pixels	NTSC: 1020(H)x508(V) / PAL: 1020(H)x596(V)
Picture Elements	NTSC: 520K Approx. / PAL: 610K Approx.
Horizontal Resolution	750TV Lines
Minimum Illumination	0 Lux (with IR-LED on)
Lens	6 mm
Electronic Shutter Speed	Auto: 1/60(50)s~1/100,000sec Manual: 1/60(50)s, FL1/120(100)s, 1/250s, 1/500s, 1/1,000s, 1/2,000s, 1/4,000s, 1/10,000s
OSD Menu	Build-in Multi-layers semi-opacity Menu Setting
WDR	WDR real wide dynamic rang compression
Digital Slow Shutter	X2 ~ X256
Digital Noise Reduction	2D/3D-NR
Auto Gain Control	ON/OFF
Back Light Comp.	HLC / BLC / OFF
Auto White Balance	AWB / ATW
Digital Demist Process	ON/OFF
Digital Zoom	Zoom 256X
Digital Day & Night Mode	On (Black & White)/Auto/External input/off (color)
Privacy Masking Function	ON/OFF (8 Editable area)
ICR	Yes
Blemish Compensation	Static & Dynamic (4096 points)
Face Tracking Auto Zoom	ON/OFF
Face Detection	ON/OFF
Face Metering Compensation	ON/OFF
Motion Detecting Function on	ON/OFF
Flash Suppression Function	ON/OFF
Image Quality Adjustment	Brightness / Contract / Saturation / Sharpness / Hue
S/N Ratio	Max. 52dB (AGC off)
Language	Multi-Language
Operation Temperature	-5°C ~ +60°C
Sync System	Internal
Scanning System	2 : 1 Interlace
Video Output	1Vpp/75Ω
Power Source Supply	12VDC(+/-10%)
Weight	2 lbs Approx.
Dimension (mm)	74x85x124
IR LEDs	28pcs, φ5mm
