Thông số kỹ thuật

Bảo hành	18 tháng

Đặc điểm nổi bật

Model AVN222 Network Network Compression H.264 / MPEG4 / MJPEG LAN Port YES LAN Speed 10/100 Based-T Ethernet Supported Protocols DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP Frame Rate NTSC: 30, PAL: 25 Number of Online

Model	AVN222
Network
Network Compression	H.264 / MPEG4 / MJPEG
LAN Port	YES
LAN Speed	10/100 Based-T Ethernet
Supported Protocols	DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP
Frame Rate	NTSC: 30, PAL: 25
Number of Online Users	10
Security	Multiple user access levels with password protection
	(1) Web browsers, such as Internet Explorer, Mozilla FireFox or
Web management	Google Chrome for single device access, or (2) Free CMS software, Video Viewer, for up to 16 network
	cameras control simultaneously
Camera
Image Sensor	1/3" HR color CCD
Pixels	771(H) x 492(V) / 753(H) x 582(V)
Min Illumination	0.15 Lux / F1.4
Shutter Speed	1 / 60 (1/50) to 1 / 100,000 sec.
S/N Ratio	More than 48dB (AGC off)
Lens	f4.0mm ~ f9.0mm
Viewing Angle	75° ~ 36°
Smart Zoom	YES
White Balance	ATW
AGC	Auto
IRIS Mode	AES (default) / AI
IR Shift	Fixed
Power Source (±10%)	DC 12V / 2.9W
Current Consumption (±10%)	600mA
Dimensions	124.3(Ø) x 102(H)
Others
Mobile Surveillance		iPhone, BlackBerry, WinCE, J2ME & Android
Motion Detection		YES
Alarm and event Notification		By FTP and Email
		‧Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD ‧256 MB RAM
Minimum Web Browsing Requirements		‧AGP graphics card, Dire ct Draw, 32MB RAM ‧Windows 7, Vista, XP, 2000 Server, ME, 98, DirectX 9.0 or later
		‧Internet Explorer 6.x or later
