Thông số kỹ thuật

Bảo hành	18 tháng

Đặc điểm nổi bật

+ FEATURES (1) 1/3" Color CCD with Sony Effio DSP (2) Super High resolution to 600 TV lines (3) Super image quality (4) Low light sensitivity of 0.1 Lux at F2.0, 0 Lux (IR ON) (5) IP67 standard approved case (6) Day and night features for 24-hour

+ FEATURES

(1) 1/3" Color CCD with Sony Effio DSP

(2) Super High resolution to 600 TV lines

(3) Super image quality

(4) Low light sensitivity of 0.1 Lux at F2.0, 0 Lux (IR ON)

(5) IP67 standard approved case

(6) Day and night features for 24-hour surveillance

+ SPECIFICATIONS*

MODEL	AVC452ZBP
Pick-up Element	1/3” Color CCD image sensor with Sony Effio DSP
Number of Pixels	771(H) x 492(V) (NTSC) / 753(H) x 582(V) (PAL)
Min. Illumination	0.1 Lux / F2.0, 0 Lux (IR ON)
Resolution	Up to 600 TV lines
IR LED	21 units
IR Effective Distance	Up to 15 meters
S/N Ratio	More than 48dB (AGC OFF)
Electronic Shutter	1/60 (1/50) to 1/100,000 sec.
Lens	f3.6mm / F2.0
Lens Angle	92.6°
Color Rolling Suppress	YES
IRIS Mode	AES
White Balance	ATW
Video Output	1.0 Vp-p composite, 75 Ω
Startup Temperature	0°C~40°C
Operating Temperature	-20°C~40°C
Power Source	DC12V
Current Consumption (±10%)	70mA (IR OFF), 270mA (IR ON)
Dimensions (mm)**	60 (Ø) x 90.13 (L)
IP Rating	IP67
