Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

- Measuring Voltage Range: 6kV ~ 81.5kV - Operation Start Voltage (To ground): 2.7kV - Display: Light : flashing red light, Sound : intermittent sound 50 dB apart 3 m - Overall Length: Retracted : 1370 +/- 50mm, Extracted : 2450 +/- 50mm - Frequency:

- Measuring Voltage Range: 6kV ~ 81.5kV
- Operation Start Voltage (To ground): 2.7kV
- Display: Light : flashing red light, Sound : intermittent sound 50 dB apart 3 m
- Overall Length: Retracted : 1370 +/- 50mm, Extracted : 2450 +/- 50mm
- Frequency: 50 / 60Hz
- Operating Temperature-10 degree C ~ +50 degree C
- Battery: 2 button cells LR44 (1.5V)
- Weight: 590g (battery included)
- Accessories: Instruction manual, carrying case
- COMMON RATINGS
- Withstand Voltage (On insulating rod): 100kV / 300mm : 5 minutes
- Insulation Resistance: 2000M Ohm min. by 1kV/DC megger at the same testing location as withstand voltage
- Leakage Current: 100uA or less than 100uA at withstand voltage test
- ConstructionWater proof (detecting head impervious to water)
