Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Output Voltage : 0 ~30V Output Current : 0 ~ 3A Resolution : 50mV/5mA Input Voltage : 220VAC – 50/60Hz Source effect CV≤5×10-4 +3 mV Load effect CV≤5×10-4 +3 mV Ripple&Noise CV ≤1 mV Dimensions (WxHxD) : 130x190x270mm Weight (kg) : 5

Output Voltage : 0 ~30V
Output Current : 0 ~ 3A
Resolution : 50mV/5mA
Input Voltage : 220VAC – 50/60Hz
Source effect     CV≤5×10-4 +3 mV
Load   effect     CV≤5×10-4 +3 mV
Ripple&Noise     CV ≤1 mV
Dimensions (WxHxD) : 130x190x270mm
Weight (kg) : 5
Features :
+ Utilizing SMT technology
+ Large LCD for voltage output
+ Automatic conversion of stable voltage and current
+ With the function of voltage and current pre-set
+ With on-off switch for DC output
+ With S+, S- sampling connectors
+ Extention output connectors
+   It adopts limited current protection for current protection, the current limiting point can be wantonly adjusted
Manufacture : China
