Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Voltage Output : 0~30V Current Output : 0~3A Resolution : 10mV /10mA Input Voltage 110-127V AC±10% 60Hz 220-240V AC±10% 50Hz Switchable Source effect CV≤1×10-4 +3mV CC≤2×10-3 +3mA Load effect CV≤1×10-4 +3mV CC≤2×10-3 +3mA Ripple

Voltage Output : 0~30V
Current Output : 0~3A
Resolution : 10mV /10mA
Input Voltage     110-127V AC±10% 60Hz
220-240V AC±10% 50Hz Switchable
Source effect     CV≤1×10-4 +3mV
CC≤2×10-3 +3mA
Load   effect     CV≤1×10-4 +3mV
CC≤2×10-3 +3mA
Ripple&Noise     CV≤1mV rms/3mVp-p
CC≤3mArms
Display Accuracy     Volt meter (0.2Rdg+2digits)
Ampere meter (1Rdg+2digits)
Dimensions (WxHxD) : 135x180x280mm
Weight (kg) : 5

One-way output, utilizing SMT technology inside
A current limit protection methods and the current Limit point can be discretional regulation
All-plastic box, good and novel appearance
Automatic temperature-control and radiation system
Manufacturer : Ningbo - China
