Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Power Consumption 2130 W (2670 VA) (at rated output), 750 W (950 VA) (IEC 65), 58 W (110 VA) (at no signal), 13 W (14 VA) (standby) Input 0 dB*, 10 kΩ, transformer-balanced, removable terminal block (3 pins) Rated Output 1200 W Load Impedance 100 V

Power Consumption	2130 W (2670 VA) (at rated output), 750 W (950 VA) (IEC 65), 58 W (110 VA) (at no signal), 13 W (14 VA) (standby)
Input	0 dB*, 10 kΩ, transformer-balanced, removable terminal block (3 pins)
Rated Output	1200 W
Load Impedance	100 V line, 8.3 Ω, M4 screw terminal, distance between barriers: 9 mm
Frequency Response	80 - 15,000 Hz , within ±3 dB (1 kHz)
Distortion	Under 0.1% (at 1 kHz rated output)
S/N Rated	Over 90 dB, 20 - 20,000 Hz band pass
Control Input	Volume control bypass control input: No-voltage make contact input, open voltage: Under 24 V DC, short-circuit current: Under 10 mA, removable terminal block (2 pins)
Indicator	Power (green), Signal (green), Peak (red), Fault (red), Bypass (orange)
Cooling	Forced air cooling (Under 50℃: Stop, 50℃ - 75℃: Low to high speed (variable), Over 75℃: High speed)
Operating Temperature	0℃ to +40℃
Operating Humidity	Under 90% RH (no condensation)
Finish	Panel: Aluminum, black, Alumite
Dimensions	482 (W) × 132.6 (H) × 532.7 (D) mm
Weight	35.4 kg
Accessory	Terminal cover …1, Terminal cover mounting screw …2, Removable terminal plug (2 pins) …2, Removable terminal plug (3 pins) …2
Option	Amplifier auto switching module: YA-7000
