Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Specification AC A 5127 6 15 60 150 300A f.s.reading ± 3% AC V 150 300 750V f.s.reading ± 3% DC V 75V f.s.reading ± 3% Ω 0 ~ 1kΩ Central scale 30Ω Rx1 Rx100 Scale length ± 3% Temperature scale -50ºC ~ +200ºC (with optional probe) Scale length ± 3%

Specification
AC A	5127
AC A	6 15 60 150 300A
	f.s.reading ± 3%
AC V	150 300 750V
AC V	f.s.reading ± 3%
DC V	75V f.s.reading ± 3%
Ω	0 ~ 1kΩ Central scale 30Ω Rx1 Rx100
Ω	Scale length ± 3%
Temperature scale	-50ºC ~ +200ºC (with optional probe)
Temperature scale	Scale length ± 3%
Protective system	Protection in Ω range up to AC250V commercial power input.
Core conductor diameter	Ф 33mm
Dimensions	190H x 78W x 34D (mm)
Weight	Approx.340g
Max.usable circuit voltage	AC 750V
Drop proof	From one meter above concrete floor
Operating environment	0ºC ~ +40ºC 70%RH max.
Storage environment	-10ºC ~ +50ºC 70%RH max.
Fuse	0.5A/250V ) Ф 6.4 x 30 (non arcing type) Internal resistance 1.8 Ω
Accessories	9067 (test leads)…….1 1.5V Battery R6P (AA)…1, Spare fuse (0.5A/250V)….1, Strap band…1, Instruction Manual…1
	9351 (Carrying case)…1
Optional accessories	9021-01 Temperature probe
