Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Diameter of measurable conductor0.177” or 4.5 mm maxOperating temperature-10 to 50 ºCStorage Temperature-25 to 60ºCOperating HumidityOperating Altitude0 to 2000 mIP RatingIP 40Size59 x 38 x 212 mm, (2.32 x 1.5 x 8.35 in.)Weight260G, (9.1 oz.

Diameter of measurable conductor	0.177” or 4.5 mm max
Operating temperature	-10 to 50 ºC
Storage Temperature	-25 to 60ºC
Operating Humidity	< 90% @ <30 ºC, < 75% @ 30 to 55ºC
Operating Altitude	0 to 2000 m
IP Rating	IP 40
Size	59 x 38 x 212 mm, (2.32 x 1.5 x 8.35 in.)
Weight	260G, (9.1 oz.)
Vibration	Random 2 g, 5 to 500 Hz
Shock	1 meter drop test (except the jaw)
EMI/RFI	Meets EN61326-1 Note: For current measurement w/ JAW, add 1mA to specification for EMC field strengths of 1V/m up to 3V/m.
Temperature Coefficient	0.01% ºC (<18? or > 28?)
Power, battery life	(2) AA 1.5 V Alkaline, IEC LR6, 40 hours typical
Warranty	Three years for electronics; One year for cable and clamp assembly
mA measurement (Measured by clamp)	Resolution and Range	0 to 20.99 mA
	Accuracy	0.2% +2 counts
	Resolution and Range	21.0 mA to 100.0 mA
	Accuracy	1% + 5 counts
