Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

SpecificationsFunctionRangeResolutionAccuracyAC Current via jaw600A0.1 A2% ± 5 digitsAC current via iFlex (optional)2500A0.1 A3% ± 5 digitsDC current600A0.1 A2% ± 5 digitsAC Voltage600V0.1 V1.5% ± 5 digitsDC Voltage600V0.1 mV1% ± 5 digitsResistance60

Specifications
Function	Range	Resolution	Accuracy
AC Current via jaw	600A	0.1 A	2% ± 5 digits
AC current via iFlex (optional)	2500A	0.1 A	3% ± 5 digits
DC current	600A	0.1 A	2% ± 5 digits
AC Voltage	600V	0.1 V	1.5% ± 5 digits
DC Voltage	600V	0.1 mV	1% ± 5 digits
Resistance	60,000 Ω	0.1 Ω	1% ± 5 digits
Frequency	500 Hz	0.1 Hz	0.5% ± 5 digits
Capacitance	1 µF to 1000 µF	1 µF	1% ± 4 digits
True-RMS	Included
Continuity	Included
Hold	Included
Backlight	Included
Min/Max/Avg	Included
Inrush	Included
Wire capacity	750 MCM or 2-500 MCM
Safety rating	CAT III 1000 V, CAT IV 600 V
