Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

317 Electrical SpecificationsCurrent ACRange 40.00 A, 600.0 AResolution 0.01 A, 0.1 AAccuracy 1.6% ± 6 digit (50-60 Hz) {40 A} 2.5% ± 8 digit (60-500 Hz) {40 A} 1.5% ± 5 digit (50-60 Hz) {600 A} 2.5% ± 5 digit (60-500 Hz) {600 A}Crest Factor add 2

317 Electrical Specifications

Current AC

Range	40.00 A, 600.0 A
Resolution	0.01 A, 0.1 A
Accuracy	1.6% ± 6 digit (50-60 Hz) {40 A}
	2.5% ± 8 digit (60-500 Hz) {40 A}
	1.5% ± 5 digit (50-60 Hz) {600 A}
	2.5% ± 5 digit (60-500 Hz) {600 A}
Crest Factor add 2% into spec for CF > 2	3.0 Max @ 500 A, 2.5 Max @ 600 A
AC response	rms

Current DC

Range	40.00 A, 600.0 A
Resolution	0.01 A, 0.1 A
Accuracy	1.6% ± 6 digit (40 A)
	1.5% ± 5 digit (600 A)

Voltage AC

Range	600.0 V
Resolution	0.1 V
Accuracy	1.5% ± 5 digit (20-500Hz)
AC response	rms

Voltage DC

Range	600.0 V
Resolution	0.1 V
Accuracy	1% ± 4 digit

Resistance

Range	400.0 Ω, 4000 Ω
Resolution	0.1 Ω, 1 Ω
Accuracy	1% ± 5 digit

Continuity

≤ 30 Ω

Inrush

Integration time

N/A

Frequency

Range	N/A
Accuracy	N/A
Trigger Level	N/A

General Specifications

Digital Display

6000 count resolution

Low Battery Indication

Displays a signal when the batteries are below their required voltage

Power Source

Three AAA IEC LR03 batteries

Clamp Opening Size

1.45 in (37 mm)

Jaw Diameter

1.45 in (37 mm)

Dimensions (L x W x H)

	6.39 in x 2.29 in x 1.20 in
	(162.4 mm x 58.25 mm x 30.5 mm)

Weight

approximately 13.5 oz (384 g) (batteries included)

Auto Range

Available in Ohms

Safety

	CE
	EN/IEC 61010-1 and IEC 61010-2-032
	Measurement Category: 600V CAT III

Environmental Specifications

Operating Temperature

14°F to 122°F (-10 °C to 50 °C)

Storage Temperature

-40 °F to 140 °F (-40 °C to 60 °C)

Operating Humidity

	Non condensing (< 50 °F) (< 10 °C)
	90 % RH (50 °F to 86 °F) (10 °C to 30 °C)
	75 % RH (86 °F to 104 °F) (30 °C to 40 °C)
	45 % RH (104 °F to 122 °F) (40 °C to 50 °C)
	(Without Condensation)
