Model
|
HT5D30
|
|
GENERATOR
|
Type
|
Three phase synchronous generator, Brushless, Self excited with AVR
|
|
Construction
|
Single bearing, Direct coupled, Self lubricated, Self ventilated
|
|
Insulation and protection
|
Class H with tropicalization, IP21 (other protection on request)
|
|
Voltage regulation
|
0.25% + 1.5%, cos φ = 0.8 + 1.0
|
|
Frequency
|
Hz
|
50 / 60
|
|
Output
|
Standby
|
kVA
|
330 / 350
|
|
kW
|
264 / 280
|
|
Prime
|
kVA
|
300 / 320
|
|
kW
|
240 / 256
|
|
Rated voltage
|
V
|
220 / 380 ; 240 / 415
|
|
Phase - Wire - Cos φ
|
3 - 4 - 0.8
|
|
ENGINE
|
Model
|
BF6M101c-g1
|
|
Type
|
Diesel 4 stroke, water cooled
|
|
Cylinder arrangement
|
V6
|
|
Bore x Stroke
|
mm
|
132 x 145
|
|
Aspiration
|
Turbo, CAC
|
|
Total displacement
|
l
|
11.9
|
|
Rated speed
|
rpm
|
1500 / 1800
|
|
Rated output
|
Tối đa
|
hp
|
402.4/ 431.6
|
|
kW
|
300.2 / 322.0
|
|
Liên tục
|
hp
|
363.5 / 390.1
|
|
kW
|
271.2 / 291.0
|
|
Governor type
|
Electronic
|
|
Starting motor
|
DC - 24V
|
|
FUEL
|
Tank capacity (Open/SoundProof)
|
l
|
600 / 800
|
|
Consumption
|
25%
|
l/h
|
18.0 / 22.1
|
|
50%
|
34.7 / 39.3
|
|
75%
|
51.8 / 58.1
|
|
100%
|
70.3 / 78.6
|
|
Lub. Oil Capacity (sump)
|
l
|
34
|
|
Coolant Capacity
|
l
|
91.0
|
|
Dimensions (Open/SoundProof)
|
Length
|
mm
|
2500 / 3900
|
|
Width
|
1400 / 1500
|
|
Height
|
2200 / 2300
|
|
Dry weight (Open/SoundProof)
|
Kg
|
2100 / 3000
|
|
Specifications are subject to change without period notice
|
