MEASUREMENTS |
DUAL ELEMENT TRANSDUCER MEASUREMENT MODE |
Time interval from a precision delay after the excitation pulse to the first echo |
|
THICKNESS RANGE |
0.50 mm to 635 mm (0.020 in. to 25.0 in.) depending on material, transducer, surface conditions, temperature |
|
MATERIAL VELOCITY RANGE |
0.508 mm/μs to 18.699 mm/μs (0.020 in./μs to 0.7362 in./μs) |
|
RESOLUTION (SELECTABLE) |
Low: 0.1 mm (0.01 in.)
Standard: 0.01 mm (0.001 in.) |
|
TRANSDUCER FREQUENCY RANGE |
2.25 MHz to 10 MHz (–3 dB) |
GENERAL |
OPERATING TEMPERATURE RANGE |
-10 °C to 50 °C (14 °F to 122 °F) |
|
KEYPAD |
Sealed, color-coded keypad with tactile and audible feedback |
|
CASE |
Impact-resistant and water-resistant, gasketed case with sealed connectors. Designed for IP65. |
|
DIMENSIONS (W X H X D) |
84.0 mm x 152.4 mm x 39.6 mm (3.31 in. x 6.0 in. x 1.56 in.) |
|
WEIGHT |
340 g (12 oz) |
|
POWER SUPPLY |
3 AA alkaline batteries |
|
BATTERY LIFE OPERATING TIME |
150 h of typical battery life, 30 h continuous use with backlight |
|
EXPLOSIVE ATMOSPHERE |
Safe operation as defined by Class I, Division 2, Group D, as found in the National Fire Protection Association Code (NFPA 70), Article 500, and tested using MIL-STD-810F 511.4 Procedure I |
|
STANDARDS |
Designed for EN15317 |
|
ALARM MODE |
Programmable Hi/Low set points with audible and visual indicators |
DISPLAY |
DISPLAY HOLD/BLANK MODE |
Holds or blanks the display after measurements |
|
BACKLIGHT |
Electroluminescent backlight, Selectable as On or Auto On |
|
RECEIVER BANDWIDTH |
1 MHz to 18 MHz (–3 dB) |
|
METRIC/ENGLISH MODE |
Metric or English units |
|
DISPLAY LANGUAGES |
English, French, German, Spanish, Italian,Portuguese, Russian, Polish, and Swedish |
