Item
|
CE5000-40-CRP
|
CE5000-60
|
CE5000-120
|
CPU
|
32-bit CPU
|
Configuration
|
Grit rolling
|
Drive system
|
Digital servo
|
Maximum cutting area
|
375 mm x 50 m
|
603 mm x 50 m
|
1213 mm x 50 m
|
Range of guaranteed precision
|
356 mm x 2 m*1
|
584 mm x 5 m*1
|
1194 mm x 5 m*1
|
Compatible media widths
|
Minimum: 50 mm
Maximum: 484 mm
|
Minimum: 50 mm
Maximum: 712 mm
|
Minimum: 85 mm
Maximum: 1346 mm
|
Maximum media thickness
|
0.25 mm
|
Maximum cutting speed
|
60 cm/s (in all directions)
|
100 cm/s (45°direction)
|
Specifiable cutting speeds
|
1-10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60 cm/s
|
1-10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, * cm/s
|
Cutting force
|
0.2-2.9N (20 gf to 300 gf) (31 levels)
|
0.2-4.4N (20 gf to 450 gf) (38 levels)
|
Minimum character size
|
Approximately 5 mm for alphanumeric characters
(varies depending on the medium, font, etc.)
|
Mechanical resolution
|
0.005 mm
|
Programmable resolution
|
GP-GL: 0.1/0.05/0.025/0.01 mm; HP-GLTM *2: 0.025 mm
|
Repeatability precision
|
0.1 mm or less per 2 m*1
|
No. of pens mountable
|
1 pen
|
Compatible cutter type
|
Supersteel cutter blades
|
Compatible pen type
|
Water-based fiber-tip pens
|
Compatible cutting film
|
Marking film (PVC, fluorescent, or reflective film) up to 0.25 mm in thickness (excluding high-luminosity reflective film)
|
Interfaces
|
RS-232C/USB 2.0 (Full Speed)
|
Buffer capacity
|
2 MB
|
Command modes
|
GP-GL, HP-GLTM *2(selected on the control panel)
|
Display panel
|
Liquid crystal display (16 characters x 1 row)
|
Rated power supply
|
100 to 240 V AC, 50/60 Hz
|
Power consumption
|
100 VA
|
Operating environment
|
10°C to 35°C, 35% to 75% RH
|
Conditions for guaranteed precision
|
16°C to 32°C, 35% to 70% RH
|
External dimensions
(W x D x H)*3
|
Approx. 623 x 285 x 223 mm
|
Approx. 851 x 585 x 1004 mm
|
Approx. 1,487 x 744 x 1194 mm
|
Weight*3
|
Approx. 9.4 kg
|
Approx. 25 kg
|
Approx. 40 kg
|
